Full Kitset Price:

$29,899

(including GST)

Plus delivery direct to your property, for just $799

Flat rate New Zealand wide, excluding outer islands, (some conditions may apply).

Download Tech Brochure

Download this free PDF for plans & more details

Alpine Cabin Kitset

Name: Alpine Cabin Kitset - SheShed New Zealand
Brand: SheShed
SKU: ALP-U
Price: 29899 NZD
Availability: InStock

5.5m x 3.5m = 19 Square Metres

Like it's smaller sisters, (the Tussock and Coastal cabins), this 19m² Alpine Cabin Kitset comes with 45mm thick solid-timber walls for better natural insulation, as well as both ColorSteel roofing and roof insulation included in the kitset price. As always, all doors and windows are double-glazed to modern high standards, and these new windows feature the European-style tilt and turn opening system to allow for natural airflow circulation while keeping the weather out. (The window can be either tilted inwards at the top for air circulation, or opened fully like a traditional casement window!)

Specifications

Because we're all about those sweet details. (Click here to get down to the nitty-gritty!)

Shed Dimensions:

5.5m x 3.5m = 19 Square Metres

Height (External):

2.71 Metres

(Excluding foundation)

Wall Thickness:

45mm (Double tongue & groove)

Timber Type:

Sustainably Sourced, Kiln-Dried, Nordic Spruce

Timber Treatment:

Natural Untreated

Glass Glazing:

Roof Style:

Modern Monopitch

Roof Material:

ColorSteel

Download the Technical Brochure for plans & more details

Structure Classification: This kitset cabin is designed to New Zealand Standards as a 7.0 Outbuilding structure. Upgrading this cabin to meet the requirement's of a Housing structure requires additional materials and work.

Inclusions

Your flatpack comes with everything you need - including the roof and floor!

x5 European Tilt & Turn Windows
Untreated timber | Double glazed | Can tilt open at the top for ventilation, or turn handle the other direction to swing it inwards like a door | Exterior frame dimensions: 720mm wide x 1975mm high | Opening dimensions: 440mm wide x 1590mm high. | sku: IWN1
Wide Double Doors
Untreated timber | Double glazed | External frame dimensions: 1840mm wide x 1975mm high | Doorway/Opening dimensions: 1560mm wide x 1790mm high. | sku: IDR1
Roof insulation
30mm Expol sheets included for under-roof insulation.
Untreated, Kiln-Dried Timber
(Except for floor beams and joists which are required to be treated at an H3.2 level). Please note: All timber components must be properly painted for protection from the sun and weather.
FSC certified sustainable forestry
Nordic Spruce, sustainably sourced from Sweden, Finland, and Latvia.
COLORSTEEL Roofing
Official COLORSTEEL 5-rib roofing & flashings. | Default colour: Grey Friars
Hardware & Components
Includes all the nails, screws, handles, locks and other hardware required to assemble your kitset.
Comprehensive build instructions
We're always working on improving our build instructions; providing step-by-step illustrations, plans and photographs plus a detailed video overview of the process.
Build support available
We're available by phone and email (during business hours), to help support you and your builder during the construction of your kitset cabin. Happy customers who love their finished cabin make our world go around!

Warranty

Learn about our exceptional waranty and 5-star guarantee.

Enjoy our 5-Star Guarantee!

★ Exceptional build support - We make it easy!
★ Full kit supplied - Yes, It actually includes the roof & floor!
★ No delays, just delight - We strive to stock every size and style, for rapid delivery.
★ Easy to follow instructions for a DIYer - You won’t be pulling your hair out.
★ European quality and craftmanship - We care about the finish.

Click here for our warranty details plus our full terms and conditions.

Build Information

Everything you need to know to bring your DIY cabin dream to life.

• Skill Level: Suitable for DIY / Home handyman, but sound building knowledge or trade skills are also recommended.

• Estimated time to assemble kitset:

6-12 Days

(2 People are recommended).

Plan for additional time for site preparations like levelling the site and building a foundation or subfloor, as well as time afterwards to fully paint the finished cabin.

• Need a hand? Check out our list of recommended builders to find one in your area: CLICK HERE to Find A Builder (opens in a new tab).

• Tools & Equipment. Here's a list of the tools and equipment we recommend having on hand to assemble your kitset: CLICK HERE to see the tools (opens in a popup).

Optional Upgrades

Customise your cabin with extra windows, doors, sub-bases and more...

Additional Doors & Windows:

Other Addons:

Payment Options

Pay in full for immediate dispatch, or reserve your cabin with a 50% deposit. Finance options available.

Option One Pay in Full:

We strive to have all our cabins available in stock, so when you pay in full, we can dispatch your cabin almost immediately. (Usually on a truck and on it's way to you within 1-3 days!)

Option Two Pay a Deposit:

Paying a 50% deposit secures your cabin from our next available stock so you don’t miss out. You can then pay the remainder once you’re ready for delivery, or we can hold your order in stock for up to 2 months.

Option Three Get Finance:

You'll deal directly with your finance provider for what you need, then once approved, you can place your order with us over the phone or here on our website. We recommend talking to MTF Finance Richmond.

At the Checkout page you'll be given the following payment methods:

Pay via credit or debit card

Pay securely online with your Credit or Debit Card. (Please note a 1.5% surcharge applies for invoices over $15k)

Secured by Windcave:

Pay via direct bank transfer

Make your payment directly into our bank account in NZ dollars. Your order will not be shipped until the funds have cleared in our account. (Details provided after order is placed)

Pay a 50% Deposit

Secure cabin now for delayed delivery

Buy Now / Add to Order

Pay in full for quick delivery
